Smooth Pu Round Belting In Roll With High Stretch , Orange Color

  • Smooth Pu Round Belting In Roll With High Stretch , Orange Color
  • Smooth Pu Round Belting In Roll With High Stretch , Orange Color
  • Smooth Pu Round Belting In Roll With High Stretch , Orange Color
  • Smooth Pu Round Belting In Roll With High Stretch , Orange Color
  • Smooth Pu Round Belting In Roll With High Stretch , Orange Color
Place of Origin china
Brand Name jiuna
Certification ROHS
Model Number diameter2-20m
Minimum Order Quantity 10 rolls
Packaging Details Inner packing is plastic film .outer packing is carton
Delivery Time Within 5 working days After receipt of your deposit
Payment Terms L/C, T/T, L/C, Western Union, MoneyGram
Supply Ability 100,000,00 as per month
Product Details
Color Orange Hardness 85A-90A
Longth 30m/roll Surface Smooth
Type PU Rough Round Belt Material PU
High Light

pu extruded belt

,

green round belt
Leave a Message
Product Description


Smooth Pu Round Belting In Roll With High Stretch , Orange Color
1) made of PU material, easy to be joint at high heat.
2) Available to add nylon cord or steel cord
3) Tolerant temperturer: -35℃--80℃
4) High capacity on wear-resistance, flexibity. Wildly applied in varies industries such as
 textile, package, printing, machinery, electricity electronics, glass,ceramics, ESPECIALLY in
ceramic/marble, they are welcome in the polishing& glazing .
5) Round belt:
 a:  diameter: 2mm--30mm
b:  surface: vivid color with glossy surface; neat granule spread fairly for rough surface type.
Features:
PU round belt has many advantages
Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Applications:
PU round belt is widely used in the following industry.
Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled
 ( m )

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30


Service commitment:
“Quality for keeping going ,Credit to win the world” http://www.polyurethane-round-belt.com/
Smooth Pu Round Belting In Roll With High Stretch , Orange Color 0Smooth Pu Round Belting In Roll With High Stretch , Orange Color 1Smooth Pu Round Belting In Roll With High Stretch , Orange Color 2Smooth Pu Round Belting In Roll With High Stretch , Orange Color 3
