PU Round Conveyor Urethane Belts Industrial Transmission 80A

China PU Round Conveyor Urethane Belts Industrial Transmission 80A supplier
PU Round Conveyor Urethane Belts Industrial Transmission 80A supplier PU Round Conveyor Urethane Belts Industrial Transmission 80A supplier PU Round Conveyor Urethane Belts Industrial Transmission 80A supplier PU Round Conveyor Urethane Belts Industrial Transmission 80A supplier

Large Image :  PU Round Conveyor Urethane Belts Industrial Transmission 80A

Product Details:

Place of Origin: China
Brand Name: Jiuna
Certification: ROHS
Model Number: Diameter 2mm~20mm

Payment & Shipping Terms:

Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 96.000 meters per Month
Contact Now
Detailed Product Description
Hardness: 85 Shore A Color: Dark Green
Material: PU Length: 30m/roll
Stretching Rete: 1.5-3% Type: PU Round Belt
Main Function: Drive,transmission Test Method: DIN Standard

PU Round Conveyor Urethane Belts Industrial Transmission 80A



Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set



PU Cord Belt Application :
 1.   Widely used in textile
 2.   printing and packing machine
 3.   food & beverage processing
 4.   wood processing
 5.   paper processing
 6.   electronic
 7.   post service
 8.   tobacco transmission line
 9.   Wall floor tile conveying industrial line
10.  Ceramic industry line or polishing line



PU  Round Belt(smooth/rough)
(1)Thermoplastic polyurethane material, easy to be melted jointed,100% pure polyurethane
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35℃ - 80℃
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics.
 Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and
other industries, especially in the ceramic industry, widely used in the facilities line the glaze,
 polishing lines, and transmission line.
(6) Dia. is from 2mm to 30mm. Smooth Belt with good surface finish; Rough belt with even surface roughness.
They are used widely.



Items No. φ

least radius of gyration

stretch rate

Maximum tensile rate

Hardness

length of rolled

DIA

(mm)

In

mm

Stretching rate

Kg

Lbs

Hardness

(A)

Roll

(m)

2mm

0.79

20

1.5-3%

0.3

0.7

90

400m

3mm

0.98

25

1.5-3%

0.7

1.6

90

400m

4mm

1.38

35

1.5-3%

1.2

2.7

85

200m

5mm

1.57

40

1.5-3%

2.0

4.3

85

100m

6mm

1.97

50

1.5-3%

3.2

7.0

85

100m

7mm

2.17

55

1.5-3%

4.1

9.0

85

100m

8mm

2.56

65

1.5-3%

5.0

11.0

85

100m

9mm

2.95

75

1.5-3%

6.8

15.0

85

50m

10mm

2.95

75

1.5-3%

7.7

17.0

85

50m

12mm

3.94

100

1.5-3%

12.2

27.0

85

30m

15mm

4.72

120

1.5-3%

17.7

39.0

85

30m

18mm

5.71

145

1.5-3%

25.4

56.0

85

30m

20mm

6.30

160

1.5-3%

31.3

69.0

85

30m



PU Round Conveyor Urethane Belts Industrial Transmission 80A
