Pu Super Grip 90A Hardness PU Polyurethane V Belt Top pvc
| Place of Origin | China |
|---|---|
| Brand Name | Jiuna |
| Certification | ROHS |
| Model Number | A-13 ,B-17 ,C-22 |
| Minimum Order Quantity | 10rolls |
| Packaging Details | Inner packing is plastic film .outer packing is carton |
| Delivery Time | Within 5 working days After receipt of your deposit |
| Payment Terms | T/T, 50% payment in advance ,50% balance before shipment |
| Supply Ability | 96.000 meters per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | A-13 B-17 C-22 | Material | PU |
|---|---|---|---|
| Standard Or Nonstandard | Standard | Packing(m/roll) | 30 |
| Application | For Ceramics & Stone/Food/Electronic/Logistics & Airport Industry,textile Printing Electronic Glass Ceramic | Hardness | 85 Shore A ~90 Shore A |
Product Description
White PU polyurethane Super Grip Belt with Top green PVC Vee Corrugated belt
Super grip Belt Feature :
· Profile shape: Vee
· Profile size: A/13, B/17, C/22
· Reinforcement: None
· Color: Green, Red
· Compliancy: RoHS
· Durometer: 80A, 90A
· Material: Polyurethane, PVC Top Surface
· Special Feature: PVC Grip Top Surface
· Package Length: 30meter /roll
· Easily welded endless vee belt
Super grip Belt of application :
· Widely used in conveying slippery environments,
· Up steep inclines conveying industrial .
Specification
| X(mm) | H(mm) | Z(mm) | M/rolls | reinforced | arabesquitic |
A | 13 | 8 | 3.5 | 30 | · | · |
B | 17 | 11 | 3.5 | 30 | · | · |
C | 22 | 14 | 3.5 | 30 | · | · |
D | 32 | 19 | 3.5 | 30 | · | · |
M | 8 | 4 |
| 50 |
|
|
Z | 10 | 5 | 3.5 | 50 | · | · |
Products introduction:
Super grip belt ,Conveying applications that require the elasticity of an unreinforced V-belt combined with a super grip surface.
Perfect for conveying in the most abrasive environments such as moving concrete blocks, bricks, and tiles of all types.
Service commitment:
“Quality for keeping going ,Credit to win the world”
