6mm Diameter green rough round cord polyurethane round belt for transmission

  • 6mm Diameter green rough round cord polyurethane round belt for transmission
  • 6mm Diameter green rough round cord polyurethane round belt for transmission
  • 6mm Diameter green rough round cord polyurethane round belt for transmission
  • 6mm Diameter green rough round cord polyurethane round belt for transmission
Place of Origin China
Brand Name Jiuna
Certification ROHS
Model Number Diameter 2mm~20mm
Minimum Order Quantity 2000 Meter
Packaging Details Inner packing is plastic film .outer packing is carton
Delivery Time Within 5 working days After receipt of your deposit
Payment Terms T/T, 50% payment in advance ,50% balance before shipment
Supply Ability 96.000 meters per Month
Product Details
Material PU Color Orange
Hardness 90 Shore A Length 400m/roll 200m/roll 100m/roll 50m/roll 30m/roll
Appl.Temperature -35/+75 Elongation 550%-650%
High Light

pu round belt

,

pu extruded belt
Leave a Message
Product Description

6mm Diameter  green  rough round cord polyurethane round belt for transmission

Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

Dia.

(mm)

 In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)
2mm 0.79 20 1.5-3% 0.3 0.7 90 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 400
4mm 1.38 35 1.5-3% 1.2 2.7 85 200
5mm 1.57 40 1.5-3% 2.0 4.3 85 100
6mm 1.97 50 1.5-3% 3.2 7.0 85 100
10mm 2.95 75 1.5-3% 7.7 17.0 85 50
12mm 3.94 100 1.5-3% 12.2 27.0 85 30
15mm 4.72 120 1.5-3% 17.7 39.0 85 30
18mm 5.71 145 1.5-3% 25.4 56.0 85 30
20mm 6.30 160 1.5-3% 31.3 69.0 85 30



Features:

1) made of PU material, easy to be joint at high heat.

2) Available to add nylon cord or steel cord

3) Tolerant temperturer: -35℃--80℃

4) High capacity on wear-resistance, flexibity. Wildly applied in varies industries such as textile, package, printing, machinery, electricity electronics, glass,ceramics, ESPECIALLY in ceramic/marble, they are welcome in the polishing& glazing .

5) Round belt:

 a:  diameter: 2mm--30mm

b:  surface: vivid color with glossy surface; neat granule spread fairly for rough surface type.

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.



Service commitment:

“Quality for keeping going ,Credit to win the world”

6mm Diameter green rough round cord polyurethane round belt for transmission 06mm Diameter green rough round cord polyurethane round belt for transmission 16mm Diameter green rough round cord polyurethane round belt for transmission 2
