Green and orange color smooth and rough Industrial Transmission urethane round belt Polyurethane Cord connected

Place of Origin China
Brand Name Jiuna
Certification ROHS
Model Number Diameter 2mm
Minimum Order Quantity 500pics
Packaging Details Inner packing is plastic film .outer packing is carton
Delivery Time Within 5 working days After receipt of your deposit
Payment Terms T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability 96.000 meters per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Length 400m/roll 200m/roll Hardness 90 A
Color Orange And Green Material PU
Model Number PU Round Belt Diameter 2mm-20mm
High Light

pu round belt

,

pu extruded belt

Leave a Message
Product Description

Industrial Transmission urethane round belt Polyurethane Cord connected

PU Cord Properties :

-High tensile strength

-Excellent abrasion resistance

-Good resistance to fuel , oils and oxygen

-Contains no plasticizer

-Wide application temperature from -30℃~+80℃



Polyurethane cord Application

-Printing and folding machine

-Newspaper conveying

-Packing machine

-Ceramic and stone ware

-Processing, Plants, Canneries

-Conveying, Wood working machine

-Paper and Cardboard converting

-industry conveying line



our factory is located in wuxi city shitang bay mountain luoshe town industrial park,

near to 312 national road, trafifc is very convenient .

Company has the international leading level of polyurethane products production  line,

the introduction of international  advanced technology and testing, testing equipment.

we already have 2,000 square meters of factory buildings,  3  advanced production lines .

We have workers about 80 people, each machine operator has more than three years of

work experience is. Factory production capacity of 96.000 meters per Month. According to

your drawing production, or the production according to your samples you need.

After the production of the product, there is a special quality manager, product testing.

To ensure that the pass rate products.



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30
