RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt

  • RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt
  • RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt
  • RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt
  • RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt
Place of Origin china
Brand Name JIUNAI
Certification ROHS
Model Number PU v belt
Minimum Order Quantity 10 rolls
Payment Terms Western Union, MoneyGram, T/T
Product Details
Material Import PU Material Color Red Color
Length 30m/roll Type V Belt
Surface Smooth Application Transmission Belt
High Light

green round belt

,

pu extruded belt

,

rohs approved polyurethane v belt
Leave a Message
Product Description

RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed

Product Description

TPU V Belts
Specifications
PU V belt
Details:
(1) Thermoplastic polyurethane material, easy to be melted jointed
(2) Reinforced by Polyester Cord or Steel Cord
(3) Temperature range -35 - 80
(4) Shore A hardness range 80A - 98A
(5) With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6) Round Belt:
Round Belt Dia. Is from 2mm to 30mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.
(7) V-belt
Specifications include the A, B, C, D, M, Z type
Widely used in ceramic industry, excellent wear resistance





Specification

X(mm)

H(mm)

 Hardness (Shore A)

M/rolls

Reinforced

A

13mm

8

    90A

30

·

B

17mm

11

    90A

30

·

C

22mm

14

    90A

30

·

D

32mm

19

    90A

30

·

M

8mm

4

    90A

50



Z

10mm

5

    90A

50

·







RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt 0RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt 1RoHS Approved Polyurethane V Belt Easy To Be Melted Jointed polyurethane flat belt 2
