PU Polyurethane Extruded V Belt Transmission Belt

Place of Origin CHINA
Brand Name VOLTA
Certification ROHS
Model Number A-13 ,B-17 ,C-22
Minimum Order Quantity 10 rolls
Packaging Details Inner packing is plastic film .outer packing is carton
Delivery Time Within 5 working days After receipt of your deposit
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 96,000,00 m per month
Product Details
Hardness 90 A Material Import PU Material
Heat-resistant -30℃-80℃ Length 30m/roll 50M/roll
Usd In Ceramic Industry Type PU V Belt
High Light

green round belt

,

pu extruded belt

,

90 A Polyurethane Extruded V Belt

Leave a Message
Product Description





PU Polyurethane Extruded V Belt Transmission Belt







We offer a complete line of PU Polyurethane Extruded V Belt Red &100m roll for use in transmission industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is hotpress welding , overlap welding .



The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .



Features:

  • Outstanding abrasion resistance
  • High tensile and tear strength
  • Resistance to oils, fuels,and oxygen
  • Good weatherability and high impact resistance
  • Low compression set



Application:

  • Newspaper conveying,
  • Packing machines,
  • Ceramic and stoneware processing plants,
  • Floor and roof tiles conveying,
  • Wood Working machineries,
  • Textile machines,
  • Paper industry machines,
  • Food grading machines, other food processing machines





PU V belt


(1) Thermoplastic polyurethane material, easy to be melted jointed.

(2) Reinforced by Polyester Cord or Steel Cord.

(3) Temperature range -35 celsius degree - 80celsius degree.

(4) Shore A hardness range 80A - 98A.

(5) With excellent resistance to flex, abrasion resistance, easy jointed and Other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.

(6) Round Belt:
Round Belt Dia. Is from 2mm to 30mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.

(7 )V-belt Specifications include the A, B, C, D, M, Z type
Widely used in ceramic industry, excellent wear resistance.

(8) Pentagon Belt, Septangular Belt, Suppergrip belt
Specifications include A, B, C three type.

(9) Hexagonal Belt
Specifications include C

(10) Parallel Belt
Including A, B two specifications

Applications:


Mainly used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, glass, chemicals, automobiles, beverages, furniture, toys, paper and other industries; Especially in the ceramic industry, widely used in the glazing Lines, transmission lines, polishing line etc.
Normal specifications including Z, M, A, B, C, D and the Pentangular Belt including A, B, C type, pentagonal belt normally used in the production line's corner.





Specification

X(mm)

H(mm)

 Hardness (Shore A)

M/rolls

Reinforced

A

13

8

    90

30

·

B

17

11

    90

30

·

C

22

14

    90

30

·

D

32

19

    90

30

·

M

8

4

    90

50



Z

10

5

    90

50

·





PU Polyurethane Extruded V Belt Transmission Belt 0
