SGS ISO9001: 2008 Certified Temperature Tolerant (-35ºC--80ºC) PU Round Belt with Diameter 2-20mm
| Minimum Order Quantity | 2,000 |
|---|
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | PU | Inside Material | PU |
|---|---|---|---|
| Feature | Tear-Resistant, Wear-Resistant | Antistatic Coefficient | Fromsix Of The 10 Party To Nie Of The 10 Party |
| Diameter Range | 2mm--30mm | Temperature Tolerance | -35ºC--80ºC |
| Hardness | Shore A 85~90 | Stretching Rate | 1.5-3% |
| Maximum Tensile Rate | Varies By Diameter (see Table) | Least Radius Of Gyration | Varies By Diameter (see Table) |
| Surface Options | Smooth Or Rough | Reinforcement Options | Polyester, Nylon Or Fibers |
| Tensile Strength | Strong | Length Of Rolled | Varies By Diameter (see Table) |
| Main Function | Drive Transmission | ||
| Highlight | SGS ISO9001: 2008 Certified PU Round Belt,Temperature Tolerant PU Round Belt,Diameter 2-20mm PU Round Belt |
||
Product Description
Black Antistatic PU Round Belt
3m - 12mm Tensile Strength PU Round Belt designed for packing machines and industrial applications.
Key Features
- Constructed from durable PU material for easy high-heat jointing
- Optional reinforcement with nylon cord or steel cord available
- Temperature tolerance range: -35°C to 80°C
- Exceptional wear-resistance and flexibility
- Wide diameter range: 2mm to 30mm
- Ideal for multiple industries including textile, packaging, printing, machinery, electronics, glass, and ceramics
- Particularly effective for ceramic/marble polishing & glazing applications
Product Specifications
| Diameter (mm) | Least Radius (in/mm) | Stretching Rate (%) | Max Tensile (kg/lbs) | Hardness Shore(A) | Roll Length (m) |
|---|---|---|---|---|---|
| 2 | 0.79/20 | 1.5-3 | 0.3/0.7 | 95 | 400 |
| 2.5 | 0.87/22 | 1.5-3 | 0.4/0.9 | 95 | 400 |
| 3 | 0.98/25 | 1.5-3 | 0.7/1.6 | 90 | 400 |
| 3.5 | 1.18/30 | 1.5-3 | 0.95/2.1 | 90 | 400 |
| 4 | 1.38/35 | 1.5-3 | 1.2/2.7 | 90 | 200 |
| 5 | 1.57/40 | 1.5-3 | 2.0/4.3 | 90 | 100 |
| 6 | 1.97/50 | 1.5-3 | 3.2/7.0 | 90 | 100 |
| 7 | 2.17/55 | 1.5-3 | 4.1/9.0 | 90 | 100 |
| 8 | 2.56/65 | 1.5-3 | 5.0/11.0 | 90 | 100 |
| 9 | 2.95/75 | 1.5-3 | 6.8/15.0 | 90 | 50 |
| 10 | 2.95/75 | 1.5-3 | 7.7/17.0 | 90 | 50 |
| 12 | 3.94/100 | 1.5-3 | 12.2/27.0 | 90 | 30 |
| 15 | 4.72/120 | 1.5-3 | 17.7/39.0 | 90 | 30 |
| 18 | 5.71/145 | 1.5-3 | 25.4/56.0 | 90 | 30 |
| 20 | 6.30/160 | 1.5-3 | 31.3/69.0 | 90 | 30 |
Additional Information
Our complete line of Polyester and Polyurethane Round belts are engineered for transmission industrial machines and product conveyance applications, including transport machines, conveyor systems, glass, and tile handling.
Available with both smooth and rough surfaces, these belts can be reinforced with polyester, nylon, or fibers. We also provide welding capabilities to create custom O-rings.
The elastic and flexible PU material (85A-90A) makes these belts particularly suitable for lead-in conveyors and vertical shaft applications.
Note: We supply all necessary connecting tools and accessories including clamps, electric irons, and knives. Connection methods include hotpress welding and overlap welding.
