8mm Oil-Resistant PU Conveyor Belt with Diameter 2-20mm for Drive Transmission

  • 8mm Oil-Resistant PU Conveyor Belt with Diameter 2-20mm for Drive Transmission
Minimum Order Quantity 1,000
Price 0.5

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model NO. DIA 2mm-20mm Type PU Round Belt
Material PU Inside Material PU
Surface Smooth Or Rough Tensile Strength 55n/mm2
Diameter Range 2 ~20 Mm Hardness Shore(A) 85 ~90
Stretching Rate 1.5-3% Maximum Tensile Rate Kg (varies By Diameter)
Least Radius In (varies By Diameter) Roll Length Roll(m) (varies By Diameter)
Feature Oil-Resistant, Acid And Alkali Resistant, Tear-Resistant, Heat-Resistant, Cold-Resistant, Wear-Resistant Abrasion Resistance Outstanding
Impact Resistance High
Highlight

8mm PU Conveyor Belt

,

Oil-Resistant PU Conveyor Belt

,

Diameter 2-20mm PU Conveyor Belt
Leave a Message
Product Description
8mm PU Conveyor Belt for Driving

Our high-performance Polyurethane (PU) round belts are designed for transmission applications in industrial machinery and product conveyance systems. These belts are ideal for transporting various materials including glass, tile, and other industrial products.

Key Features:
  • Outstanding abrasion resistance
  • High tensile and tear strength
  • Resistance to oils, fuels, and oxygen
  • Excellent weatherability and impact resistance
  • Low compression set
  • Available with smooth or rough surfaces
  • Reinforced with polyester, nylon, or fibers
  • Can be welded into O-rings
Applications:
  • Newspaper conveying systems
  • Packing machines
  • Ceramic and stoneware processing plants
  • Floor and roof tiles conveying
  • Wood working machinery
  • Textile machines
  • Paper industry machines
  • Food grading and processing machines
Technical Specifications:
Items NO. Φ Least Radius of Gyration Stretching Rate Maximum Tensile Rate Hardness Length of Roll
DIA(mm) In mm % Kg Lbs Shore(A) Roll(m)
2mm 0.79 20 1.5-3% 0.3 0.7 95 400
2.5mm 0.87 22 1.5-3% 0.4 0.9 95 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 400
3.5mm 1.18 30 1.5-3% 0.95 2.1 90 400
4mm 1.38 35 1.5-3% 1.2 2.7 90 200
5mm 1.57 40 1.5-3% 2 4.3 90 100
6mm 1.97 50 1.5-3% 3.2 7 90 100
7mm 2.17 55 1.5-3% 4.1 9 90 100
8mm 2.56 65 1.5-3% 5 11 90 100
9mm 2.95 75 1.5-3% 6.8 15 90 50
10mm 3.94 100 1.5-3% 7.7 17 90 50
12mm 3.94 100 1.5-3% 12.2 27 90 30
15mm 4.72 120 1.5-3% 17.7 39 90 30
18mm 5.71 145 1.5-3% 25.4 56 90 30
20mm 6.3 160 1.5-3% 31.3 69 90 30
